LOSAN Pharma’s new stick pack forming, filling and sealing lines have been fully operational and breakdown free, for the 13,400 hours – and counting – since its integrated Domino label and camera control systems went live.
Domino’s printing expertise, an intelligent camera solution from Cognex and image processing software from Krempien+Petersen were combined for Losan’s stick pack lines.
Since the print and verification system was installed nine months ago, all four of the new two-line MERZ packing machines have been operational 24/7.
Losan Pharma’s Head of Production Dr Johannes Trapp said: “We needed to establish an innovative labelling system with camera control for several packaging lanes operating independently of each other. For this purpose, all the printers and control cameras need to be controlled from a central control panel."
"To meet our requirements, we decided on the Domino G320i thermal inkjet OEM boards, together with KUPvision camera control, since this solution seemed best suited to meet our requirements. We also found that we could integrate both the printers and the control cameras into the MERZ stick pack machines without any issues."
The system’s centralised touchscreen industrial PC is used to input text, visualise test results, monitor printer status and parameterise test systems after setup. Its ability to store error patterns acts as a warning system, which works to keep label information accurate.
Specifically designed for original equipment manufacturers (OEMs) and system integrators, Domino’s G320i OEM board fits seamlessly into the target system and is controlled by its HMI.
The system’s four print heads in four different print groups offer OEMs a wealth of configuration options for printing pinpoint-sharp codes at high production speeds. The inclusion of cameras within the bespoke labelling solution provides the quality scrutiny to ensure Losan Pharma’s print and data accuracy before products leave the facility.
Quick dry, pin sharp character coding
To ensure quick drying times and high contrast, Domino experts specified the use of ethanol-based BK118 pharmaceutical ink to print the product’s expiry date and batch number onto the stick packs.
BK118 delivers uniform, permanently readable character coding at high production speeds. Domino’s specification for the use of BK118 pivoted on the ink’s abrasion resistance in plastic film prints.
Based on decades of experience, Domino engineered a solution in which the printing, camera checking and drying processes all happen within a half-second window.
Optimum print and inspection
Produced in line with the latest regulations and recommendations, KUPvision mark and vision software connects intuitively and conveniently to print and inspection systems.
KUPvision is suitable for sectors beyond pharmaceutical, auto and food industries and, like Domino’s print systems, the hardware is modular by design. That adaptability has proven key to solutions devised under the partnership.
The smooth integration of modular components forms an important part of Domino’s offering and it matched Dr Trapp’s expectations. “I would highly recommend Domino as a systems supplier," he added.
